10 Most Common Questions Asked About Thermal Printheads - Answered!

Thermal printheads are a vital part and extremely sensitive and expensive. Important care and maintenance is important to the optimal functioning.

Below are a collection of questions and answers to help provide you with information and direction to follow to get the most out of your printheads :

1. Why is preserving the printhead life important?

• save money as printheads are very expensive
• reduce poor print quality and marginally scannable bar codes, due to worn out printheads

2. What causes wear to the printhead ?

• friction
• prolonged use at high printhead energies (i.e. heat)
• excessive buildup or ink residue on the printhead
• misuse or abuse by the operator

3. What protects the printhead from abrasion?

• a thin, hard coating over the heating elements protect them from abrasion while providing efficient heat transfer
• the ribbon also protects the printhead from abrasion damage. It is separates the printhead from the printing substrate to shield it from abrasive movements, and also has a lubricated backcoat that allows it to flow smoothly over the printhead

4. What causes abrasive damage to printheads ?

• when a label or tag stock is wider than the ribbon (which causes the media on either side of the ribbon’s edges passes directly over the printhead ).
• using a ribbon with an ineffective backcoat
• using inappropriate media for thermal transfer
• improper cleaning of the printhead
• some ribbons with backcoats specially formulated to clean the printhead

5. How can abrasive damage be recognized?

• the first sign is usually a decrease in image quality

• also can be failure of one or more heating elements, which shows as a “white line” through the printed image where the printhead no longer has the ability to transfer ink


6. Do quality ribbons require lower energy settings?

• yes, a ribbon and substrate combination that is matched for optimum print quality at the lowest energy settings can extend printhead life

7. What is "Printhead Buildup"?

• buildup is the accumulation of deposits of ink, ribbon backcoat, paper particles, label adhesive, dust, dirt, etc. over time

8. When does printhead buildup become a problem?

• buildup becomes a problem when maintenance guidelines are not followed and print quality results

• any deposit on the printhead , if not removed regularly, can insulate the heating elements from the ribbon and thus require printing at higher energy settings, which can ultimately shorten printhead life

• burned-out pixels in the printhead result in unscannable bar codes


9. How to prevent buildup from becoming a problem?

• purchase a good quality ribbon and printing substrate

• minimize the accumulation of dust by keeping the printer cover closed

• follow the OEM’s recommended operating, maintenance, and printhead cleaning schedule

10. How long will a printhead last if the best possible ribbons are used?

• this will depend on the printhead design and other factors such as printer speed, energy settings, static, substrate, and ribbon quality

• a good ribbon should be guaranteed not to cause significant degradation due to buildup or abrasion throughout the printhead’s rated life

• the industry standard is that the printhead should last for one million linear inches of use
